Installing the FortiGate unit Package Contents
FortiGate-200, FortiGate-300, FortiGate-400, FortiGate-500 and FortiGate-1000 FortiOS 3.0 MR4 Install Guide
01-30004-0267-20070215 15
Installing the FortiGate unit
This section provides information on installing and setting up the FortiGate unit on
your network. This section includes the following topics:
• Package Contents
• Air Flow
• Mechanical loading
• Powering on the FortiGate unit
• Connecting the FortiGate unit
Package Contents
Review the contents of your FortiGate package to ensure all components were
included.
FortiGate-200
The FortiGate-200 package contains the following items:
• FortiGate-200 Unified Threat Management System
• one orange crossover Ethernet cable (Fortinet part number CC300248)
• one grey straight-through Ethernet cable (Fortinet part number CC300249)
• one null-modem cable (Fortinet part number CC300247)
• one power cable
• two 19-inch rack mount brackets
• FortiGate-200 QuickStart Guide
• Fortinet Tools and Documentation CD
Figure 1: FortiGate-200 package contents
Front
Back
DMZ
CONSOLE
INTERNAL
EXTERNAL
INTERNALPOWER STATUS
EXTERNAL
DMZ
DMZ
Interface
External
Interface
Internal
Interface
Status
LED
Internal, External,
DMZ Interface LEDs
Power
LED
RS-232 Serial
Connection
Removable
Hard Drive
Power
Connection
Power
Switch
Power Cable
Rack-Mount Brackets
Null-Modem Cable
(RS-232)
Ethernet Cables:
Orange - Crossover
Grey - Straight-through
Documentation
FortiGate-200
