FortiGate-200, FortiGate-300, FortiGate-400, FortiGate-500 and FortiGate-1000 FortiOS 3.0 MR4 Install Guide
28 01-30004-0267-20070215
Factory defaults
Table 9: Factory default NAT/Route mode network configuration
Factory default Transparent mode network configuration
In Transparent mode, the FortiGate unit has the default network configuration
listed in Table 10 .
Table 10: Factory default Transparent mode network configuration
Factory default firewall configuration
FortiGate firewall policies control how all traffic is processed by the FortiGate unit.
Until firewall policies are added, no traffic can be accepted by or pass through the
FortiGate unit. To allow traffic through the FortiGate unit, you can add firewall
policies. See the FortiGate Administration Guide for information about adding
firewall policies.
The following firewall configuration settings are included in the default firewall
configuration to make it easier to add firewall policies.
Administrator
account
User name: admin
Password: (none)
Internal interface
IP: 192.168.1.99
Netmask: 255.255.255.0
Administrative Access: HTTPS, Ping
External interface
Port 2 (FortiGate-400)
IP: 192.168.100.99
Netmask: 255.255.255.0
Administrative Access: Ping
DMZ/HA interface
Port 3 and
Port 4/HA
(FortiGate-400)
IP: 10.10.10.1
Netmask: 255.255.255.0
Administrative Access: HTTPS, Ping
Default Gateways (for default route) 192.168.100.1
Network Settings
Default Route
A default route consists of a default gateway and the name of
the interface connected to the external network (usually the
Internet). The default gateway directs all non-local traffic to this
interface and to the external network.
Primary DNS Server 65.39.139.53
Secondary DNS Server 65.39.139.63
Administrator
account
User name: admin
Password: (none)
Management IP
IP: 0.0.0.0
Netmask: 0.0.0.0
DNS
Primary DNS Server: 65.39.139.53
Secondary DNS Server: 65.39.139.63
Administrative access
Internal HTTPS, Ping
External Ping
DMZ HTTPS, Ping
