Foster Solo Plus - Probe Resistance Values; Fuse Ratings

9. PROBE RESISTANCE VALUES
The air and defrost probes have the following temperature resistance values (K ohms)
Temperature Kohms Temperature Kohms
+50°C 4,161 0°C 27,280
+40°C 5,828 -10°C 42,450
+30°C 8,313 -20°C 67,740
+20°C 12,090 -30°C 111,300
+10°C 17,960 -40°C 188,400
10. FUSE RATINGS
NOTE: LA refers to Low Ambient Models
FOSTER CODE Internal fuse Wiring diagram
SP101HW 16 A J1018
SP201HW 16 A J1018
SP301HW 20 A J1018
SP401HW 25 A J1018
SP501HW No fuses J2020
SP601HW No fuses J2019
SP101LW 20 A J1018
SP201LW No fuses J2019
SP301LW No fuses J2019
SP101HW LA 16 A J1019
SP201HW LA 16 A J1019
SP301HW LA 20 A J1019
SP401HW LA 25 A J1019
SP501HW LA No fuses J2021
SP601HW LA No fuses J2022
SP101LW LA 20 A J1019
SP201LW LA No fuses J2022
SP301LW LA No fuses J2022
12
