2. SOLO PLUS TECHNICAL DATA
Foster Nom. HP Cut Out HP Cut In Suction Valve Noise Heat Rejected RoomVent 32°C Ambient 43°C Ambient Air Air Vol Electrical Nominal Defrost Condensate Net Gross
Model No. HP Press Bar Press Bar Press Bar Level dBa Max Watts @ 32°C
m
3
/ h # Watts Room Cap Watts Room Cap Throw mts m
3
/ h
Volts
Phase
Hz
Amps Watts Type Vaporisation Wt. Kg Wt. Kg
NOTE: The condenser fan pressure stat fitted on Low Ambient units should be set at 17bar with a 1.5bar differential, this applies to high and low temperature models.
SP 101HW 0.375 28 23 ------ 58 1900 700 1300 11 1160 8 4 600 230 1 50 3.9 600 Hot Gas Auto 53 74
SP 201HW 0.5 28 23 ------ 60 2050 700 1450 13 1200 11 4 600 230 1 50 5.5 600 Hot Gas Auto 56 77
SP 301HW 0.75 28 23 ------ 60 2700 700 1800 16 1550 14 4 600 230 1 50 5.6 900 Hot Gas Auto 64 85
SP 401 HW 0.75 28 23 ------ 60 3650 1400 2550 25 2200 20 4 1200 230 1 50 7 1100 Hot Gas Auto 80 110
SP 501HW 1 28 23 ------ 62 5100 1400 3100 33 2700 27 4 1200 400 3 50 5.2 1800 Hot Gas Auto 80 110
SP 601HW 1.5 28 23 ------ 63 6900 1500 4700 58 4000 48 9.5 1800 400 3 50 5.9 2200 Hot Gas Auto 100 135
STORAGE TEMP +10°C
Foster Ref Qty Capillary Size
Model No. Gas Grms No. x Dia x Len
SP 101HW R404A 0.67 1 x 1.5 x 2500
SP 201HW R404A 0.67 1 x 1.5 x 2500
SP 301HW R404A 0.64 1 x 1.8 x 2000
SP 401HW R404A 1.10 1 x 2.0 x 2900
SP 501HW R404A 0.88 2 x 1.8 x 2500
SP 601HW R404A 1.11 2 x 2.0 x 2000
Foster Nom. HP Cut Out HP Cut In Suction Valve Noise Heat Rejected RoomVent 32°C Ambient 43°C Ambient Air Air Vol Electrical Nominal Defrost Condensate Net Gross
Model No. HP Press Bar Press Bar Press Bar Level dBa Max Watts @ 32°C
m
3
/ h # Watts Room Cap Watts Room Cap Throw mts m
3
/ h
Volts
Phase
Hz
Amps Watts Type Vaporisation Wt. Kg Wt. Kg
SP 101HW 0.375 28 23 ------ 58 1650 700 1050 7 900 6 4 600 230 1 50 3.9 600 Hot Gas Auto 53 74
SP 201HW 0.5 28 23 ------ 60 1756 700 1150 9 1050 7 4 600 230 1 50 5.5 600 Hot Gas Auto 56 77
SP 301HW 0.75 28 23 ------ 60 2356 700 1450 13 1300 10 4 600 230 1 50 5.6 900 Hot Gas Auto 64 85
SP 401 HW 0.75 28 23 ------ 60 3000 1400 1900 20 1600 14 4 1200 230 1 50 7 1100 Hot Gas Auto 80 110
SP 501HW 1 28 23 ------ 62 4500 1400 2700 30 2350 24 4 1200 400 3 50 5.2 1800 Hot Gas Auto 80 110
SP 601HW 1.5 28 23 ------ 63 6300 1500 4100 50 3300 35 9.5 1800 400 3 50 5.9 2200 Hot Gas Auto 100 135
Foster Nom. HP Cut Out HP Cut In Suction Valve Noise Heat Rejected RoomVent 32°C Ambient 43°C Ambient Air Air Vol Electrical Nominal Defrost Condensate Net Gross
Model No. HP Press Bar Press Bar Press Bar Level dBa Max Watts @ 32°C
m
3
/ h # Watts Room Cap Watts Room Cap Throw mts m
3
/ h
Volts
Phase
Hz
Amps Watts Type Vaporisation Wt. Kg Wt. Kg
SP 101HW 0.375 28 23 ------ 58 1450 700 850 6 750 5 4 600 230 1 50 3.9 600 Hot Gas Auto 53 74
SP 201HW 0.5 28 23 ------ 60 1550 700 950 7 850 6 4 600 230 1 50 5.5 600 Hot Gas Auto 56 77
SP 301HW 0.75 28 23 ------ 60 2100 700 1300 11 1200 9 4 600 230 1 50 5.6 900 Hot Gas Auto 64 85
SP 401 HW 0.75 28 23 ------ 60 2800 1400 1700 15 1400 11 4 1200 230 1 50 7 1100 Hot Gas Auto 80 110
SP 501HW 1 28 23 ------ 62 4100 1400 2300 21 2000 17 4 1200 400 3 50 5.2 1800 Hot Gas Auto 80 110
SP 601HW 1.5 28 23 ------ 63 5550 1500 3350 36 2800 26 9.5 1800 400 3 50 5.9 2200 Hot Gas Auto 100 135
Foster Nom. HP Cut Out HP Cut In Suction Valve Noise Heat Rejected RoomVent 32°C Ambient 43°C Ambient Air Air Vol Electrical Nominal Defrost Condensate Net Gross
Model No. HP Press Bar Press Bar Press Bar Level dBa Max Watts @ 32°C
m
3
/ h # Watts Room Cap Watts Room Cap Throw mts m
3
/ h
Volts
Phase
Hz
Amps Watts Type Vaporisation Wt. Kg Wt. Kg
SP 101LW 1.25 28 23 2.5 62 1950 700 1050 7 850 5 4 600 230 1 50 5.2 900 Hot Gas Auto 64 85
SP 201LW 1.5 28 23 2.5 63 3200 1400 1700 14 1400 10 4 1200 400 3 50 4.3 1500 Hot Gas Auto 80 110
SP 301LW 2.2 28 23 2.5 63 4440 1500 2700 28 2250 20 9.5 1800 400 3 50 4.5 1700 Hot Gas Auto 105 140
Foster Ref Qty Capillary Size
Model No. Gas Grms No. x Dia x Len
SP 101HW R404A 0.67 1 x 1.5 x 2500
SP 201HW R404A 0.67 1 x 1.5 x 2500
SP 301HW R404A 0.64 1 x 1.8 x 2000
SP 401HW R404A 1.10 1 x 2.0 x 2900
SP 501HW R404A 0.88 2 x 1.8 x 2500
SP 601HW R404A 1.11 2 x 2.0 x 2000
Foster Ref Qty Capillary Size
Model No. Gas Grms No. x Dia x Len
SP 101HW R404A 0.67 1 x 1.5 x 2500
SP 201HW R404A 0.67 1 x 1.5 x 2500
SP 301HW R404A 0.64 1 x 1.8 x 2000
SP 401HW R404A 1.10 1 x 2.0 x 2900
SP 501HW R404A 0.88 2 x 1.8 x 2500
SP 601HW R404A 1.11 2 x 2.0 x 2000
STORAGE TEMP +10°C STORAGE TEMP +1/4°C STORAGE TEMP 0/-2°C
STORAGE TEMP +1/4°C
STORAGE TEMP 0/-2°C
STORAGE TEMP -18/-21°C
Foster Ref Qty Capillary Size
Model No. Gas Grms No. x Dia x Len
SP 101LW R404A 0.53 1 x 1.5 x 2500
SP 201LW R404A 0.84 1 x 1.8 x 2500
SP 301LW R404A 1.13 2 x 1.6 x 2800
STORAGE TEMP -18/-21°C
