Foster Solo Plus - List of Fuses

42
POWER CURRENT FUSE: This is a fuse fitted in the line.
INTERNAL FUSES: We mean those fuses fitted in the control panel. Above list shows quantity, types and power.
N.B: All units are provided with a room light holder and a 60W. bulb. When replacing, use bulbs having a power not higher than 100
Watt.
SOLO
POWER
CURRENT FUSE
Type DIAZED
INTERNAL FUSES
MOD. Voltage n° Amp n° Dim Amp n° Dim Amp n° Dim Amp
SP1 HC 230V/1~/50 1 16 1 9x36 16
SP2 HC 230V/1~/50 1 20 1 9x36 16
SP3 HC 230V/1~/50 1 20 1 5x20 F 6
SP4 HC 400V/3~/50 3 10 1 5x20 F 6
SP5 HC 400V/3~/50 3 16 1 5x20 F 6
SP2 LC 230V/1~/50 1 20 1 5x20 F 6
SP3 LC 400V/3~/50 3 16 1 5x20 F 6
SP4 LC 400V/3~/50 3 16 1 5x20 F 6
CARD FUSE
Power fuse Auxiliary fuse
LIST OF FUSES
POWER CURRENT FUSE: This is a fuse fitted in the line.
INTERNAL FUSES: We mean those fuses fitted in the control panel. Above list shows quantity, types and power.
N.B: All units are provided with a room light holder and a 60W. bulb. When replacing, use bulbs having a power not higher than
100
Watt.
SOLO
POWER
CURRENT FUSE
Type DIAZED
INTERNAL FUSES
MOD. Voltage n° Amp n° Dim Amp n° Dim Amp n° Dim Amp
SP1 HW 230V/1~/50 1 16 1 9x36 16 1 5x20 F 6
SP2 HW 230V/1~/50 1 20 1 9x36 16 1 5x20 F 6
SP3 HW 230V/1~/50 1 25 1 5x20 F 6
SP4 HW 400V/3~/50 3 16 1 5x20 F 6
SP5 HW 400V/3~/50 3 20 1 5x20 F 6
SP1 LW 230V/1~/50 1 16 1 5x20 F 6
SP2 LW 230V/1~/50 1 20 1 5x20 F 6
SP3 LW 400V/3~/50 3 16 1 5x20 F 6
SP4 LW 400V/3~/50 3 20 1 5x20 F 6
SP5 LW 400V/3~/50 3 20 1 5x20 F 6
CARD FUSE
Power fuse Auxiliary fuse
