Foster Solo Plus - Wiring Diagrams View

45
MODEL SP 1HC SP 2HC
Drawing No. Sheet No. 81800L 1 of 1
Drawn By Approved Date Sonchl Martinelli 04-12-1997
Rev No. Date: Approved
HVC Condenser Fan Motor H22 Internal Light HVE Evaporator Fan Motor MP Door Switch (if fitted) M1 Compressor BS Defrost Probe YS Hot Gas Solenoid Valve BA Air Probe
