1-3 Back Panel Connectors
1. PS/2 Mouse Port
 Usetheupperport(green)toconnectaPS/2mouse.
2. PS/2 Keyboard Port
 Usethelowerport(purple)toconnectaPS/2keyboard.
3. VGA Port
To connect with external display devices, such as monitor or LCD display.
4. DVI-D Port
 TheDVI-DportsupportsDVI-Dspecication.ConnectamonitorthatsupportsDVI-D
connection to this port.
5. HDMI Port
 TheHDMI(High-DenitionMultimediaInterface)providesanall-digitalaudio/videointerface
to transmit the uncompressed audio/video signals and is HDCP compliant. Connect the HDMI
audio/video device to this port. The HDMI Technology can support a maximum resolution of
 1920x1080pbuttheactualresolutionssupporteddependonthemonitorbeingused.
6. Serial Port
 ThisisoutputofRS232COM1port.
7. USB 2.0 Ports
 TheUSBportsupportstheUSB2.0/1.1specication.UsethisportforUSBdevicessuchasan
 USBkeyboard/mouse,USBprinter,USBashdriveandetc.
8. Audio Ports
Forthedenitionofeachaudioport,pleaserefertothetablebelow:
Audio Ports of 6 Channel:
* : Please refer to Chapter 4, and install the Realtek audio driver (in CD) to assign the audio
outputportsfordifferentapplicationsof2/4/5.1channels.Thefundamentalaudiooutputsare
depicted in the table above.
LAN Port
PS/2MousePort
3
1
VGA Port
9
2 4
DVI-D Port
7
USB2.0PortsPS/2KeyboardPort
5
HDMI Port (Optional)
6
Serial Port (Optional)
Audio Ports(Optional)
Line Out
Microphone In
Subwoofer
Rear Speaker
Side Speaker
Line In
8
Port 2-channel 4-channel 5.1-channel
Blue Line In Rear Speaker Out* Rear Speaker Out*
Green Line Out Front Speaker Out Front Speaker Out
Pink Microphone In Microphone In Center/Subwoofer Out*

Foxconn H61MX Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
PCI Express x16	1
SATA Ports	4 x SATA 3Gb/s
Audio	Realtek ALC662
LAN	Realtek RTL8111E
Expansion Slots	1 x PCI Express x1, 1 x PCI
Video Outputs	VGA, DVI
