CPU Configuration
► Intel AES-NI
This item is used to disable or enable Advanced Encryption Standard feature.
► Intel XD Bit
This item is used to enable/disable the Execute Disable Bit feature.
Intel’s Execute Disable Bit functionality can help prevent certain classes of malicious buffer
overowattackswhencombinedwithasupportingoperatingsystem.
► Limit CPUID Maximum
ThisitemisusedtoenableordisableCPUIDmaximumvaluelimitconguration.
Set [Enabled] : the maxium CPUID is 3.Set [Disabled] for WinXP.
► Intel Virtualization Technology (Appears only when CPU supports)
Virtualization (i.e. Intel® Vanderpool Technology) allows a platform to run multiple operating
systems and applications in independent partitions or “containers.” One physical compute
system can function as multiple “virtual” systems. Vanderpool Technology can help improve
future virtualization solutions. This item will be displayed only when the CPU is supporting this
feature and the setting is used to enable or disable it.
► CPU C3 Report (Appears only when Set “Power Technology” to [Custom])
ThisitemisusedtoenableordisableCPUC3(ACPIC2)reporttoOS.
► CPU C6 report
This item is used to enable or disable CPU C6 State.
► Hyper-Threading (Appears only when CPU supports)
This item is used to enable/disable the Hyper-Threading Technology feature.
Version 2.11.1210. Copyright (C) 2012 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
F-Center
CPU Configuration
CPU Brand Name:
Intel(R) CPU @ 3.00GHz
L1 Data Cache 32 KB x 4
L1 Code Cache 32 KB x 4
L2 Cache 256 KB x 4
L3 Cache 6144 KB
Processor Stepping 6
Max CPU Speed 3000 MHz
Min CPU Speed 1600 MHz
CPU Speed 3000MHz
Processor Cores 4
Intel HT Technolony Not Supported
Intel VT-x Technolony Supported
Intel SMX Technolony Not Supported
Intel AES-NI [Disabled]
Intel XD Bit [Enabled]
Limit CPUID Maximum [Disabled]
Intel Virtualization Technolony [Disabled]
CPU C3 Report [Disabled]
CPU C6 State [Disabled]
Hyper-threading [Disabled]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Intel AES-NI
F-Center

Foxconn H61MX Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
PCI Express x16	1
SATA Ports	4 x SATA 3Gb/s
Audio	Realtek ALC662
LAN	Realtek RTL8111E
Expansion Slots	1 x PCI Express x1, 1 x PCI
Video Outputs	VGA, DVI
