Foxconn H61MX Series User Manual

3
37
Power
Version 2.14.1219. Copyright (C) 2012 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Main F-Center Advanced Boot Power Health Security Save & Exit
ACPI Sleep State [S3]
Resume By PS2 KB/Mouse [Enabled]
Resume By USB Device(s) [Enabled]
Resume By PCI PME [Disabled]
Resume By PCIE Device(s) [Disabled]
Resume By Modem Ring [Disabled]
Resume By Onboard LAN [Disabled]
Resume By RTC [Disabled]
Energy-using Products [Enabled]
Restore AC Power Loss [Power Off]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Select the highest ACPI sleep
state the system will enter
when the SUSPEND button is
pressed.
Power
► ACPI Sleep State
This item is used to set the energy saving mode of the ACPI function. When you select “S1
(POS)” mode, the power is always on and computer can be resumed at any time. When
you select “S3 (STR)” mode, the power will be down after a period of time. The status of the
computer before it entering STR will be saved in memory, and the computer can quickly return
to previous state when the STR function wakes.
► Resume by PS2 KB/Mouse
Thisitemisusedtoenable/disablethePS2keyboard/mousetogenerateawakeup.
► Resume by USB Device(s)
This item is used to wake up the system by a USB device when it is staying at S3 state.
► Resume by PCI PME
This item is used to enable/disable the PCI device to generate a wake up.
► Resume by PCIE Device(s)
This item is used to enable or disable the PCI Express device to generate a wake up.
► Resume by Modem Ring
This item is used to enable or disable the Modem Ring to generate a wake up.
► Resume by Onboard LAN
This item is used to enable or disable the onboard LAN to generate a wake up.
► Resume by RTC
This item is used to enable or disable RTC alarm event to generate a wake up.
RTC is system real time clock.
► Energy-using Products
This item is used to enable or disable the EuP(Energy-using Products) feature. When enable,
thesuspendpowerofthechipsetwillbecutoffinS5suspendmodeinordertoreducethe
power consumption of motherboard.
Enabled:S1/S3/S4isnormal,S5wakeuponlybypressingthepowerbutton.
Disabled: Normal ACPI function.
► Restore AC Power Loss

Foxconn H61MX Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
PCI Express x16	1
SATA Ports	4 x SATA 3Gb/s
Audio	Realtek ALC662
LAN	Realtek RTL8111E
Expansion Slots	1 x PCI Express x1, 1 x PCI
Video Outputs	VGA, DVI
