Foxconn H61MX Series User Manual

1
2
1-1 Product Specications
CPU SupportIntel®IvyBridge/SandyBridgeLGA1155Processors
Maxprocessorpowerupto95W
For the latest CPU information, please visit：
http://www.foxconnsupport.com/cpusupportlist.aspx
Chipset Intel
®
H61
Memory 2x240-pinDDR3DIMMs
Support up to 16GB of system memory
DualchannelDDR31333/1066MHzarchitecture
Expansion Slots 1xPCIExpress3.0x16slot
1 x PCIExpress2.0x1slot
2xPCIslots
Storage H61 chipset:
-4xSATA2.0connectors300MB/sdatatransferrate
- Support hot plug and NCQ (Native Command Queuing )
LAN Realtek 8111E Gigabit LAN chip
Audio Realtek
ALC662/ALC888Saudiochip:
-HighDenitionAudio
-2/4/5.1/7.1(Optional)-channel
- Support for S/PDIF Out
- Support Jack-Sensing function
USB H61 chipset:
-Supportupto10xUSB2.0ports(4rearpanelports,3onboardUSB
headers supporting 6 extra ports)
Internal Connectors
1x24-pinATXmainpowerconnector
1x4-pinATX12Vpowerconnector
4xSATA2.0connectors
3xUSB2.0connectors(supporting6xUSBdevices)
1 x CPU fan header (4-pin)
1 x System fan header (4-pin)
1 x Front panel connector
1 x CD_IN connector
1 x Front Audio connector
1 x SPDIF_OUT connector
1 x Speaker connector
1 x Chassis intrusion alarm header
1 x IrDA connector
1xCOM2connector
1 x TPM connector
1 x LPT connector
(Continued on the next page)
