Foxconn H61MX Series User Manual

4
63
3-3 Congure - Advance
ThispageletsyouselecttoashBIOS/BootBlockandclearCMOS.IfyouchooseFlashBoot
Block,itmeansBIOSisnotprotective,andyoumustmakesuretheashprocessiscontinuous
and without any interruption.
4. About & Help
This page shows some information about FOX LiveUpdate.
C
AUTION
!
We recommend that you had better keep the default setting unchanged to avoid any
damage.
Click here
Select which BIOS ROM
toash(Onlyavailableto
motherboard with backup
BIOS ROM )
Apply the changes
Reset to default value
SelecttoashBootBlock
Select to clear CMOS
Click here
Show information about
FOX LiveUpdate

Foxconn H61MX Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
PCI Express x16	1
SATA Ports	4 x SATA 3Gb/s
Audio	Realtek ALC662
LAN	Realtek RTL8111E
Expansion Slots	1 x PCI Express x1, 1 x PCI
Video Outputs	VGA, DVI
