F-Center
► Super BIOS Protect
To protect the system BIOS, there is a BIOS write-protection mechanism provided to prevent
BIOS FLASH tool being improperly used to update BIOS or the vicious virus(such as CHI,etc)
rewriting BIOS setup.
► Smart BIOS/Fox Intelligent Stepping/CPU Configuration/Performance Tuning
Press <Enter> to go to relative submenu.
Smart BIOS
Version 2.14.1219. Copyright (C) 2012 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Main F-Center Advanced Boot Power Health Security Save & Exit
Fox Control Center
Super BIOS Protect [Disabled]
▶Smart BIOS
▶Fox Intelligent Stepping
▶CPU Configuration
▶
Performance Tuning
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Super BIOS Protection Settings
F-Center
Version 2.14.1219. Copyright (C) 2012 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
F-Center
Smart BIOS
Smart Power LED [Disabled]
Smart Boot Menu [Enabled]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Smart Power LED Settings
F-Center

Foxconn H61MX Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
PCI Express x16	1
SATA Ports	4 x SATA 3Gb/s
Audio	Realtek ALC662
LAN	Realtek RTL8111E
Expansion Slots	1 x PCI Express x1, 1 x PCI
Video Outputs	VGA, DVI
