Foxconn H61MX Series User Manual

3
30
Advanced
► North Brigde/ME Subsystem/Onboard Device Conguration/SATA Conguration/Trusted
Computing/Super IO Conguration
Press <Enter> to go to relative submenu.
North Bridge
Version 2.14.1219. Copyright (C) 2012 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
North Bridge Configuration
Memory Information
Total Memory 2048 MB (DDR3 1333)
Memory Slot1 Not Present
Memory Slot2 2048 MB (DDR3 1333)
Memory Configuration
Integrated Graphics [Auto]
UMA Frame buffer Size [256M]
Initate Graphic Adapter [Auto]
VT-d [Disabled]
IGD Multi-Monitor [Disabled]
DVMI/FIXED Memory [256MB]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Keep IGD enabled based on the
setup options.
Advanced
► Total Memory
This item displays the current using memory information.
► Memory Slot 1/2
These items display the memory size installed on each slot.
Version 2.14.1219. Copyright (C) 2012 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Main F-Center Advanced Boot Power Health Security Save & Exit
▶ North Brigde
▶ ME Subsystem
▶ Onboard Device Configuration
▶ SATA Configuration
▶ Trusted Computing
▶ Super IO Configuration
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
North Brigde Parameters
Advanced

Foxconn H61MX Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
PCI Express x16	1
SATA Ports	4 x SATA 3Gb/s
Audio	Realtek ALC662
LAN	Realtek RTL8111E
Expansion Slots	1 x PCI Express x1, 1 x PCI
Video Outputs	VGA, DVI
