Foxconn H61MX Series User Manual

3
33
SATA Conguration
Version 2.14.1219. Copyright (C) 2012 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
SATA Configuration
Onboard SATA Controller [Enabled]
Onboard SATA Mode [Native IDE]
▶ SATA Port1:Not Present
▶ SATA Port2:Not Present
▶ SATA Port3:Not Present
▶ SATA Port4:Not Present
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
SATA Ports Device Names if
Present and Enabled.
Advanced
► Onboard SATA Controller
This item is used to enable or disable the onboard SATA controller.
► Onboard SATA Mode
This item is used to set the operating mode of your SATA ports. Setting options:[Native IDE];
[AHCI].
[NativeIDE]-ThiscongurestheSATAportstosupportnativeIDEmode.
[AHCI]-TheAdvancedHostControllerInterface(AHCI)specicationdescribestheregister
levelinterfaceforaHostControllerforSerialATA.Thespecicationincludesadescriptionof
the hardware/software interface between system software and the host controller hardware.
AHCI provides more advanced features including SATA features, but some SATA drives may
notsupportAHCI,unlesstheyarelabeledwithAHCIsupportinitsspecication.
If your motherboard supporting AHCI, and you have a SATA device, which also supports AHCI,
then you can select IDE option to have fair performance (only PATA, SATA level), or you can
select AHCI to get its best performance.

Foxconn H61MX Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
PCI Express x16	1
SATA Ports	4 x SATA 3Gb/s
Audio	Realtek ALC662
LAN	Realtek RTL8111E
Expansion Slots	1 x PCI Express x1, 1 x PCI
Video Outputs	VGA, DVI
