Foxconn H61MX Series User Manual

3
29
Memory Timing Conguration
Version 2.14.1219. Copyright (C) 2012 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Memory Multiplier Configuration
Performance Memory Profiles [Manual]
XMP Profile 1 Not Supported
XMP Profile 2 Not Supported
Memory Timing Configuration
Memory Clock Multiplier [1.33]
Memory Multiplirer [13.33]
tCL 9
tRP 9
tRCD 9
tRAS 24
tWR 10
tRFC 74
tWTR 5
tRRD 4
tRTP 5
tFAW 20
Intel Graphics Configuration
Graphics Core Ratio Limit 22
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
The selection of Performance
Memory Profiles which impacts
memory sizing behavior.
F-Center
► CAS Latency (tCL)
The number of memory clocks it takes a DRAM to return data after the read CAS_L is assert
ed depends on the memory clock frequency. The value that BIOS programs into the memory
controller is a function of the target clock frequency. The target clock frequency is determined
from the supported CAS latencies at given clock frequencies of each DIMM.
► Row Precharge Time (tRPmin)
This item allows you to select the row precharge time (in clock cycles).
► CAS to RAS(tRCDmin)
This item allows you to select a delay time (in clock cycles) between the CAS# and RAS#
strobe signals.
► Active to Precharge(tRASmin)
This item allows you to set the minimum RAS# active time (in clock cycles).
► Write Recovery(tWRmin)
This item allows you to select the write recovery time (in clock cycles).
► Refresh Recovery(tRFCmin)
Refresh to Refresh or Refresh to Active command interval.
► Internal Write to Read Command(tWTR)
This item allows you to select a delay time (in clock cycles) between sending the last data from
a write operation to the memory and issuing a read command.
► Row Active to Row Active(tRRDmin)
This item allows you to select a delay time (in clock cycles) between the RAS# and RAS#
strobe signals.
► Read CAS# Precharge Delay (tRTP)
Internal READ Command to PRECHARGE Command delay
► Four Active Window (tFAWmin)
This item allows you to specify the time window in which four activates are allowed the same
rank.

Foxconn H61MX Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
PCI Express x16	1
SATA Ports	4 x SATA 3Gb/s
Audio	Realtek ALC662
LAN	Realtek RTL8111E
Expansion Slots	1 x PCI Express x1, 1 x PCI
Video Outputs	VGA, DVI
