Foxconn H61MX Series User Manual

3
35
Super IO Conguration
Version 2.14.1219. Copyright (C) 2012 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Super IO Configuration
Super IO Chip IT8728
▶ Serial Port 1 Configuration
▶ Parallel Port Configuration
▶ CIR Controller Configuration
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Set Parameters of Serial Port
0 (COMA)
Advanced
► Serial Port 0 Conguration
Press <Enter> to go to its submenu.
Serial Port 0 Conguration
► Serial Port
This item is used to enable or disable the serial port (COM).
► Device Settings
This item shows the resource assigned to the serial port.
► Change Settings
This item is used to select an optimal settings for the serial port.
► Device Mode
This item is used to change the serial port mode.
Parallel Port Conguration
► Parallel Port
This item is used to enable or disable the parallel port.
► Device Settings
This item shows the resource assigned to the parallel port.
► Change Settings
This item is used to select an optimal settings for Super IO device.
► Device Mode
This item is used to change the parallel port mode.
CIR Controller Conguration
► CIR Controller
This item is used to enable or disable the CIR Controller.
► Change Settings
This item is used to select an optimal settings for Super IO device.

Foxconn H61MX Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
PCI Express x16	1
SATA Ports	4 x SATA 3Gb/s
Audio	Realtek ALC662
LAN	Realtek RTL8111E
Expansion Slots	1 x PCI Express x1, 1 x PCI
Video Outputs	VGA, DVI
