► Integrated Graphics
This item is used to set the mode of the Integrated Graphics.
► UMA Frame buffer Size
Allocatessystemmemoryforuseasvideomemorytoensurethemostefcientuseofavail- avail-avail-
ableresourcesformaximum2D/3Dgraphicsperformance.
ThisisamemoryallocationmethodadditiontotheUniedMemoryArchitecture(UMA)
concept, wherein a static amount of page-locked graphics memory is allocated during driver
initialization.Thisxedamountofmemorywillprovidetheuserwithaguaranteedgraphics
memory at all times, and will no longer be available to the OS.
► Initial Graphic Adapter
This item is used to select which graphics controller is used as the primary boot device.
► VT-d
This item is used to enable or disable the VT-d feature. Intel® Virtualization Technology for
Directed I/O (VT-d) can help end users improve security and reliability of the systems and also
improve performance of I/O devices in virtualized environment.
► IGD Multi-Monitor
This item is used to enable or disable the IGD Multi-Monitor by internal graphics device.
► DVMT/FIXED Memory
This item is used to select DVMT/FIXED Meory size used by Internal Graphics Device.
ME Subsystem
Version 2.14.1219. Copyright (C) 2012 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Intel ME Subsystem Configuration
ME firmware Version 8.0.2.1410
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
ME Subsystem Help
Advanced
► ME rmware Version
It displays the current ME version.

Foxconn H61MX Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
PCI Express x16	1
SATA Ports	4 x SATA 3Gb/s
Audio	Realtek ALC662
LAN	Realtek RTL8111E
Expansion Slots	1 x PCI Express x1, 1 x PCI
Video Outputs	VGA, DVI
