Foxconn H61MX Series User Manual

4
44
FOX ONE
FOX ONE is a powerful utility for easily modifying system settings. It also allows users
to monitor various temperature values, voltage values, frequencies and fan speeds at
any time.
With FOX ONE, you can :
■Modifysystemperformancesettings,suchastheCPUandmemorybusspeeds,
CPU voltages, fan speeds, and other system performance options.
■Monitorhardwaretemperatures,voltages,frequenciesandfanspeeds.
Supporting Operating Systems :
■Windows2000 ■WindowsXP(32-bitand64-bit)
■Windows2003(32-bitand64-bit) ■Windows7(32-bitand64-bit)
Using FOX ONE :
TheveryrsttimeyourunFOXONE,F.I.S.Calibrationfunction(FOXIntelligent
Stepping)willrequireyoutocalibratetheCPU’sloading.Click“OK”toproceed
and start the Utility. F.I.S. is a feature of FOX ONE, which can automatically adjust your
CPU clock based on your current system loading.
Before you running the FOX ONE program, the system parameters (such as CPU
clock, voltage...etc.) are controlled by BIOS settings. After you run FOX ONE, it will
take over, and the controlling right will be transferred to FOX ONE. Later, if you exit
FOX ONE, then BIOS control will be back again.
C
AUTION
!
Depending on hardware support, voltage monitoring and Fox Intelligent Stepping
features are optional and only supported in some models. If the option is selectable,
it also means the feature is supported.
■VoltageMonitoringissupportedonlyinFOXONEPremium&Deluxeproducts.
■FoxIntelligentSteppingissupportedonlyinFOXONEDeluxeproducts.
C
AUTION
!

Foxconn H61MX Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
PCI Express x16	1
SATA Ports	4 x SATA 3Gb/s
Audio	Realtek ALC662
LAN	Realtek RTL8111E
Expansion Slots	1 x PCI Express x1, 1 x PCI
Video Outputs	VGA, DVI
