Enhanced Intel SpeedStep
®
technology (EIST) allows the system to dynamically adjust
processor voltage and core frequency, which can result in decreased average power
consumption and decreased average heat production. There are some system require-
ments must be met, including CPU, chipset, motherboard, BIOS and operation system.
Please refer to Intel website for more information.
CAUTION
!
►Turbo Mode
Turbomodeallowsprocessorcorestorunfasterthanitsmarkedfrequencyinspeciccondi-
tion.
North Bridge Conguration
Version 2.14.1219. Copyright (C) 2012 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Memory Multiplier Configuration
Performance Memory Profiles [Automatic]
XMP Profile 1 Not Supported
XMP Profile 2 Not Supported
Intel Graphics Configuration
Graphics Core Ration Limit 21
Graphics Voltage(1/256) 0
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
The selection of Performance
Memory Profiles which impacts
memory sizing behavior.
F-Center
► Performance Memory Profiles
Thisitemisusedtoselectperformancememoryprole.
 Options:[Automatic],[Manual],[XMPProle1],[XMPProle2].
[Automatic]-Congurationdatabaseofusingperformancememoryprole.
[Manual]-Congurationdatabaseofusingperformancememoryprole.Thenextsubmenu
will apear when select this item.
[XMP Prole 1]-CongurationdatabaseofusingXMPtimingprole1.
[XMP Prole 2]-CongurationdatabaseofusingXMPtimingprole2.
► Graphics Core Ratio Limit
This item is used to set the graphics care ratio limit.
► Graphics Voltage(1/256)
This item is used to set the graphics voltage.
