Foxconn H61MX Series User Manual

2
19
Intel
®
ME Jumper: PCH_ME_ENABLE
This motherboard uses PCH_ME_ENABLE jumper to enable or disable Intel® Management
Engine function.
Intel® Management Engine (ME) is an embedded microcontroller located in Intel chipset. It
provides latest IT management features such as Intel® AMT, that allows to improve management
of corporate assets.
Setthejumpertopins1-2,youcanenabletheIntel®ManagementEnginefunction.
Setthejumpertopins2-3,youcandisabletheIntel®ManagementEnginefunction.
Enable
(Default)
1
2
3
Disable
PCH_ME_ENABLE
BeforeashingBIOSROM,youneedtosetPCH_ME_ENABLEjumpertopins2-3
 rst.
C
AUTION
!
1
2
3

Foxconn H61MX Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
PCI Express x16	1
SATA Ports	4 x SATA 3Gb/s
Audio	Realtek ALC662
LAN	Realtek RTL8111E
Expansion Slots	1 x PCI Express x1, 1 x PCI
Video Outputs	VGA, DVI
