Step 10: aGate Panel re-installation
● Two installers will be needed to re-install the aGate external panel. One installer lifts the aGate external panel up and adjusts it to
the correct position. The other installer fastens the (6) screws M4X8 sunk screws.
● Remove the knockouts at the desired positions where the breaker switches will be installed.
● Install the internal panel and fasten it by tightening the (6) M5X12 combination bolts.
Tighten it clockwise using
a #3X4 Phillips head cross
screwdriver.
Tighten it clockwise using
a #3X4 Phillips head cross
screwdriver.
63
