Franklin Home Power Overview
Meter
Electric MeteraGate Grid
D
C
A
C
aPower 1
Backup loads
Main Panel
Solar Solar inverter
Generator
Panel
aPower 3aPower 2
Whole-Home Power Backup System
The system stores electricity supplied by the grid or generated by the solar generation system and discharges as a backup power
supply for all household power loads during power failure periods or nights.
Franklin Home Power (“FHP”) is a whole-house energy solution for family users. FHP is composed of aPower as the built-in
accumulator for the inverter and aGate as the energy management unit. With proven AC coupling battery technologies, FHP
provides a reliable household backup and load control solution for family users and supports connection to residential power
generators.
Smart loads
6
