Meter
Electric MeteraGate Grid
D
C
A
C
Backup loads
Backup Panel
Solar Solar inverter
Generator
Non-essential loads
Non-backup Panel
aPower 1
Panel
aPower 3aPower 2
Backup Power System for Family Loads
The FHP system stores electricity supplied by the grid or generated by the solar generation system and discharges as a backup
power supply during power failure periods or nights to support some of your family loads. These loads are selected in the system
design process. Lower priority loads should be excluded from the backup power supply in the system configuration process.
Franklin Home Power Overview
Smart loads
