Step 8: Electrical Wiring
aGate terminal information and wiring requirements
Non –Backup lugs
Backup lugs Ground
Neutral lugs
Grid lugs
Generator lugs
L1 L2L1 L2
L1 L2 L1 L2
L1
L2
L1
L2
L1
L2
L1
L2
Solar AC breaker
aPower AC breaker
Smart Load breaker
Breakers to be installed on the
grid power supply or fuel
generators should be wired
following the breaker
manufacturer’s instructions
The wiring of breakers should follow the instructions provided by the
breaker.
