PRO-S Rev1104
14
Install Optional High Idle
The High Idle Kit (FRC part number PRO-38H) provides the necessary components
needed to install this option including a DPDT switch, 2500 ohm potentiometer, an
indicator light, two diodes, and a cable.
The high idle cap may be installed on the end of the control module high idle 3-pin
Deutsch connector. This cap is removed to install the high idle cable.
Note: Refer to the high idle calibration procedure after the installation is
complete to adjust the 2500 ohm potentiometer for high idle engine RPM.
Install the potentiometer in a location that will allow access to adjust it during the
calibration procedure.
For wiring of the high idle components refer to Figure 7. Optional High Idle
Schematic.
