PRO-S Rev1104
20
High Idle Option Calibration
The RPM that the engine will run at when the high idle circuit is engaged is set by
adjusting the 2500 ohm potentiometer.
1. Loosen the lock nut on the potentiometer.
2. Place the high idle switch to ON.
3. With a small screw driver adjust the wiper arm on the potentiometer to set the
engine RPM. (Use a reference tachometer monitor engine speed.)
4. Tighten the lock nut on the potentiometer. Ensure the engine RPM does not
change when the lock nut is tightened.
5. Place the high idle switch to OFF.
3rd Gear Lock-up RPM Calibration (Ford 6.0L)
The 3rd gear lock-up is factory set at 1200 RPM. This procedure is to change the
setting in the program.
Note: The engine must be running and the pump engaged interlock circuit
must be closed.
1. Press IDLE button.
Result: SETTING display shows IdLE.
2. Press RPM mode button to select RPM mode.
Result: RPM LED indicator goes on.
Note: The RPM display must show IdLE.
3. Press and hold PRESET button. (Continue to hold through step 5.)
Result: SETTING display flashes the programmed preset.
4. Press and release RPM mode button.
Result: SETTING display shows programmed lock-up RPM.
5. Press INCREASE or DECREASE button to change RPM setting.
6. Release PRESET button.
Result: The new 3rd gear lock-up RPM is programmed. SETTING display
shows IdLE.
