FRC PRO-S 1 - Common OME Connectors; Figure 9. Common OEM Connectors

PRO-S Rev1104
25
Commonly found
under the driver
side dashboard.
Figure 9. Common OEM Connectors
Common OME Connectors
Typical 6-pin Deutsch diagnostic connector.
Pin A J1587 Datalink Positive
Pin B J1587 Datalink Negative
Typical 9-pin Deutsch diagnostic connector.
Pin F J1587 Datalink Positive
Pin G J1587 Datalink Negative
FRONT
VIEW
B
F
E
A
C
D
G
H
J
E
D
A
B
C
F
FRONT
VIEW
