2008T Troubleshooting Guide
P/N 490292 Rev. A
OVER- 3.0.0 ISOLATE INLET WATER PRESSURE (Slow Overflow)
a) IMPORTANT! Turn the water OFF!
b) This procedure uses a psi pressure gauge. ENSURE it reads 0 psi before installing it.
c) Per the Figure below, install the gauge at Inlet Pressure Regulator #61.
Figure 100 – Inlet Pressure Regulator #61
d) IMPORTANT! Turn the water ON!
e) Place the machine into RINSE and allow one (1) minute!
f) Call debug screen 0. If debug does not appear press ‘Esc’ then call screen 0.
g) ENSURE Flow Error (TOP window) = ‘0’ ALWAYS!
h) Is gauge pressure cycling to a Peak of between 18 and 20 psi?
Yes Between 18 and 20 psi! See procedure number OVER- 3.0.1 (page 589).
No Per Figure 100 above: a) Loosen Regulator’s #61’s lock nut. b) Can the center screw be
adjusted until a PEAK between 18 and 20 psi is achieved? TWO (2) possible scenarios:
1) IF (and ONLY if) between 18 and 20 psi is achieved! See procedure number
OVER- 3.0.1 (page 589).
2) IF between 18 and 20 psi CANNOT be achieved: TWO (2) possibilities: 1) Incoming
water pressure more than 105 psi OR; 2) Bad Regulator #61. NOTE! A Regulator #61
Rebuild kit is available, P/N 190934.
To Next Page
