HPS 273 and 407 Rotary Screw Compressor
Forms
Compressor prestart checklist
The installer must check and complete the following items before the arrival of the Frick Field Service Supervisor. You can nd
details on the checklist in this manual. Certain items on this checklist are reveried by the Frick Field Service Supervisor before
the actual start-up.
Mechanical checks
o Package installed according to Frick publication
070.210-IB, Screw Compressor Foundations
o Conrm that motor disconnect is open
o Isolate suction pressure transducer
o Pressure test and leak check unit
o Evacuate unit
o Remove compressor drive coupling guard
o Remove coupling center and do not reinstall
(motor rotation must be checked without center)
o Check for correct position of all hand, stop, and check
valves before charging unit with oil or refrigerant
o Charge unit with correct type and quantity of oil
o Lubricate electric drive motor bearings before
checking motor rotation
o Check oil pump alignment, if applicable
o Check for correct economizer piping, if applicable
o Check separate source of liquid refrigerant supply (if
applicable, liquid injection oil cooling)
o Check water supply for water-cooled oil cooler (if ap-
plicable, water cooled oil cooling)
o Check thermosyphon receiver refrigerant level (if ap-
plicable, thermosyphon oil cooling)
o Check for correct pipe supports and correct foundation
o Check to ensure all piping including relief valves is
completed
o Verify that the balance piston regulator has been spec’d
for the application
o If piped in the eld, check if the balance piston regulator
has been piped correctly
o If using a motorized balance piston regulator, verify the
settings in the controller
o If using automatic main oil ow regulation, verify the
setup for the application
o Verify that the controller is set up for the suction pres-
sure limitation for the given Vi range
o Verify that the main oil injection is piped to the correct
port. For example, SM1 must only be used if the Vi range
is between 2.2 and 5.0
o Check if heat tracing and insulation is adequate for the
coldest day of the year (outside of compressor package)
o Turn on heating and heat tracing for at least 24 h before
initial start up
After checking and verifying the items in Mechanical checks, perform the following steps:
o Close the main disconnect from the main power supply to the motor starter.
o Close the motor starter disconnect to energize the micro.
o Manually energize oil pump and check oil pump motor rotation.
o Leave micro energized to ensure oil heaters are on and oil temperature is correct for start-up.
Do not energize compressor drive motor. Only authorized factory eld service technicians are to perform this.
Complete the above items before the Frick Field Service Supervisor arrives . Ensure there is an uncoupled compressor drive
unit, to verify motor rotation and alignment, and energized oil heaters with the oil at the correct standby temperatures . Full
compliance with the above items contributes to a quick, efcient, and smooth start-up.
The start-up supervisor performs the following steps:
1. Veries position of all valves
2. Veries all wiring connections
3. Veries compressor motor rotation
4. Veries oil pump motor rotation
5. Veries the percentage of FLA on the micro display
6. Veries and nalizes alignment (if applicable)
7. Calibrates slide valve and slide stop
8. Calibrates temperature and pressure readings
9. Corrects any problem in the package
Complete and sign this form and fax to 717-762-8624 as conrmation of completion:
Frick sales order number: ____________________________
Compressor model number: __________________________
Unit serial number: __________________________________
End user name: _____________________________________
Address of facility: __________________________________
City, State, Zip: _____________________________________
Print name: ________________________________________
Company: __________________________________________
Job site contact: ____________________________________
Contact phone number: ______________________________
Signed: _______________________________________
Forms
10. Instructes operation personnel
11. Verify that the Balance Piston Regulation is piped
correctly (SB2 Port) and providing the pressure
required. (Coolware)
12. Verify that the automatic regulation of main oil ow is
working correctly, if applicable.
13. Check if heating and heat tracing comes on when
compressor stops and stays on
