FRITZ!Box 6490 Cable 94
Wireless LAN—Getting Technical
Different conditions may apply for the individual ranges.
2.4 GHz and 5 GHz
The FRITZ!Box works in the wireless network in the 2.4-GHz
range and parallel in the 5-GHz range. Both frequency ranges
can be used simultaneously for wireless LAN connections.
This means you always have the optimum data connection at
your disposal:
For applications that rely on a high transmission rate as
steady as possible (“streaming”), use the 5-GHz frequency
band. This radio band provides more channels, these chan-
nels do not overlap, and they are also subject to significantly
less external interference.
For applications that require a low to normal transmission
rate (for instance, reading and writing e-mail), use the 2.4-
GHz frequency band.
Bandwidth
Depending on which generation of the IEEE 802.11n standard
is used, the FRITZ!Box can transport 300 to 450 Mbit/s over
wireless LAN. Up to 1300 Mbit/s are possible with the
IEEE 802.11ac standard. If not enough space is available in
the radio spectrum to allow interference-free transmission on
the channel with bandwidth of 40/80 MHz, the FRITZ!Box au-
tomatically reduces bandwidths to 20/40 MHz (“fallback”)
with a correspondingly lower transmission capacity.
For connections in accordance with the 802.11ac standard
with three separate data streams (three antennas), higher da-
ta throughput can be achieved with greater bandwidth:
Standard Channel Bandwidth (MHz)
802.11ac Automatic selection of 20, 40 or 80
802.11n Automatic selection of 20 or 40
802.11a 20 (always)
