Froling T4e - Product Overview T4 e

1.1 Product overview T4e
5.1
5.2
5.3
5.4
1 Wood chip boiler – Fröling T4e
2 Main switch: switches the power supply on and off for the entire system
3 High-limit thermostat STL
4 Mains connection
5 Lambdatronic H 3200 boiler controller, ⇨ See "Overview of the touch display" [page
29]
5.1 Status display (operating status), ⇨ See "Status display" [page 30]
5.2 Large touch screen for displaying and changing operating statuses and parameters
5.3 Brightness sensor to automatically adjust the display brightness
5.4 USB port for connecting a USB stick for software updates
6 Insulating cover
7 Heat exchanger cover
8 Service port
1
General
Product overview T4e
