132
Finally...
After replacing the fuse:
- Find out and correct the cause for the defective fuse
2
4
1
2
1
2
off
on
1
2
ON
3
1
1
4
2
7
3
5
6
Replacing
Fuses
NOTE Only use fuses for solar modules that meet the proper
requirements for string fuses.
Fuse dimensions: Diameter 10.3 x 35 - 38 mm
Test the fuse holder at the terminal for continuity
1
