Fronius MHP 280i G CMT - Fitting Inner Liner from Wire Buffer to FSC; Ensuring Hosepack Alignment for Liner Insertion

3 4
Fitting the inner
liner from the
wire buffer to
the FSC
NOTE!
Ensure that the hosepack is straight when fitting the inner liner, otherwise the
liner might not be inserted correctly.
1 2
** Steel inner liner
*** Plastic inner liner
3
**** Screw the cap onto the inner liner as far as
it will go. The inner liner must be visible through
the hole in the cap.
4
52
