Fronius MHP 280i G CMT - Setting the Contact Pressure; Adjusting Contact Pressure via Screw

3 4
5
Setting the con-
tact pressure
Only set the contact pressure once the wire electrode has been threaded in.
* Use the values shown on the in-
side of the cover as a guide
when setting the contact pres-
sure.
NOTE!
The contact pressure is set as follows:
▶
Turn the screw counter-clockwise = reduce the contact pressure
▶
Turn the screw clockwise = increase the contact pressure
58
