35
EN
Delay:
- charge start delay:
- Delay time (minutes) of actual start of charging relative to the moment when
charge start was initiated
- charge end delay:
- Delay time (minutes) before charge end is signalled (e.g. green indicator) relative
to the moment when charging actually stopped
Calendar - optional:
The calendar function allows charging to be started automatically according to the follow-
ing criteria:
- Time window in which charging may not be started if a battery is connected
- Time window in which charging is to be started if a battery is connected
To activate the calendar function,
select the "ON" setting and confirm
Charge:
- Time window in which charging is to be
started
(e.g. 00:00-06:00, 20:00-24:00)
Stop:
- Time window in which charging must
not take place
(e.g. 06:00-20:00)
Please note! Ongoing charging operations are affected by the set time windows.
- If in the example above a battery is connected at 05:45, charging will be stopped at
the end time defined by the set time window (in this example, at 06:00). Charging will
be resumed when the next charging phase begins.
- If the battery is connected during the "stop" time window, charging is started automat-
ically during the next time window.
Each time window can be changed in sta-
ges of 15 minutes. Up to 15 time windows
can be defined for each day.
Either "Charge" or "Stop" can be selected
for each time window.
1
Additional settings are possible under the "Calendar" function:
Day Setting 1-7:
The day settings allow up to seven differ-
ent charging phase time profiles to be de-
fined.
