Number of cells
Ah
Characteristic
Type of battery
Configuration
mode
Configuration mode provides the following setting options:
"Charging settings": settings for the battery
- Type of battery, e.g. "Wet".
- Charging characteristic, e.g. "IU".
- Capacity (Ah) or charging time (h) depending on the charging characteristic.
- Cells: voltage (V) and number of battery cells or automatic setting of the number of
cells.
CAUTION!
Danger of damage to the battery.
This may result in damage to the battery.
▶
The number of cells should only be set automatically for batteries with the fol-
lowing nominal voltages: 12 V and 24 V for 24 V devices, 24 V and 48 V for 48
V devices.
▶
Do not set the number of cells automatically for deep discharged batteries.
- Additional settings:
for individual adaptation options for the charging characteristic.
"Additional functions": Additional functions
- Blue LED
- External start/stop
- Refill indicator
- Options area
- Start charging again after a grid failure
"General options": General settings
- Language
- Contrast
- Time (hh:mm:ss)
Time zone
Daylight saving time/normal time
- Date (dd:mm:yy)
- Length of charging cable (m)
-
Charging cable cross section (mm
2
)
- AC current limitation
- Unit for temperature values
- Code for accessing the configuration menu activated/deactivated.
- Time interval for the parameters recorded on the USB flash drive (s).
- Reset statistics
- Reset history
“Reset Settings”
- Includes a double-check prompt ("OK?") that requires the operator to reconfirm that
this step is intended.
30
