18
If the chargers are arranged in a line one behind the other without being offset, the space
between the chargers must be as follows:
a) Selectiva 8 kW: Minimum distance 30 cm (11.81 in)
b) Selectiva 16-18 kW: Minimum distance 60 cm (1 ft. 11.62 in.)
Wall bracket
WARNING!
Danger due to work that has been carried out incorrectly and devices falling over.
This may result in serious injury and damage to property.
► This installation must only be carried out by trained and qualified personnel.
► Take note of the safety rules in the charger Operating Instructions.
► Different wall plugs and screws are required depending on the supporting surface.
► Wall plugs and screws are therefore not included in the scope of supply.
► The installer is responsible for selecting the correct wall plugs and screws.
WARNING!
Danger due to objects falling or toppling over.
This may result in serious injury and damage to property.
► Ensure that all screw connections are secure.
► Only use with a Fronius Selectiva 8/-18 kW charger.
► Ensure the device is level when mounting.
1 2
(a)
(b)
1
3
1
2
32
62
62
2
