Charging lights
Suitable signal lamps can be connected to the connections inside the device as illustrated
in order to indicate the state of charge or operating status of the charger. Each signal lamp
must have a working voltage of 12 V, and the total current drawn by all the lamps must not
exceed 0.5 A. Connections (1) to (5) in the figure are assigned as shown below. It is advis-
able to use the lamp colours shown below:
If the RGB setting (LED strip) is set in the menu, then connection 3 (YELLOW) is not sup-
ported. The normal setting (conventional signal lamp) or RGB (LED strip) for the "External
lamp" function is explained under "Additional functions" in the "Display" section.
Wall bracket The robust wall bracket ensures safe fitting on site. More information can be found in the
corresponding Installation Instructions.
Connection Function Colour
(1) 12 V power supply
(2) "Battery charged" indicator
- On steady: charging ended
Green
(3) "Charge" indicator
- Lit: during charging
- Flashes: if charging has been interrupted
Yellow
(4) "Fault" indicator on steady:
- Charger faulty
- While the red indicator is on, charging cannot take place
(charging interrupted).
- The relevant status code appears in the display.
"Fault" indicator flashes briefly every 3 seconds:
- The charger outputs a status code.
- Charging continues. The relevant status code number
and the state of charge appear alternately on the dis-
play.
Red
(5) "State of charge" / "Battery cooled down" on steady:
- Depending on the indicator function that has been set,
either the state of charge has exceeded the set percent-
age value or the battery has cooled down and is ready
for use.
Blue
(4)
(5)
(+)
(-)
(1)
(2)
(3)
RCS 3.0 Lights
1
2
3
4
12V
GREEN
YELLOW
RED
BLUE
Ext. Start/Stop
Ext. Start/Stop
WARNING
Hazardous Voltage
Kondensator Entladezeit < 2 min.
Capacitor discharge time < 2 min.
Décharge de condensateur < 2 min.
Condensador tiempo de descarga < 2 min.
Condensatore tempo di scaricamento < 2 min.
