31
EN
Page 2/2 shows the following values:
- Total number of charges
- Total Ah output
- Average Ah output per charge
- Total energy consumed (kWh)
- Average energy consumed (kWh) per
charge
The consumed energy display is a standard value and can deviate by up to 5% from the
actual amount of energy. At lower power levels the deviation may be higher.
History mode History mode provides information about the parameters for all the stored charging pro-
cesses. In order to show changing or different displays, two versions of the display window
are shown below:
Text content of the display window:
- Start date of charge, e.g. Mon 20/08/2014
- Duration of charge, e.g. 3h25min or charging start time, e.g.: 16:08
- State of charge at charge start, e.g. 23%
- State of charge at charge end, e.g. 100%
- Voltage at charge end, e.g. 58.6 V
- Consumed Ah, e.g. 410 Ah
- Consumed kWh, e.g. 20 kWh
- Battery ID, e.g. 12345678X
Use the "Up/Down" keys to scroll between the pages for each
stored charging process
Symbols shown
- Full battery:
Charging has been completed
- Empty battery:
Charging has not been completed
- Exclamation mark with number:
Warning has been output with the corresponding status code. More informa-
tion can be found in the "Status codes" section.
- Symbol with number:
Error has been output with the corresponding status code. More information
can be found in the "Status codes" section.
- Key symbol with a tick:
Charging was stopped properly using the "Stop/Start" key
- Key symbol with a cross:
Charging was stopped without using the "Stop/Start" key
1
