Fronius Symo 5.0-3-M Service Manual & Spare Parts List

108
Replacing other
components
WARNING!
Follow the safety rules (see start of "Safety" chapter)
If the following components are faulty, the complete inverter must be replaced:
- Housing parts (except lid)
- Inductors
- Heat sink
- Seals (except the seal on the lids)
The lids (DATCOM lid and power module lid) can be replaced as an assembly with sprayed
seal.

Fronius Symo 5.0-3-M Specifications

General

AC Nominal Output	5.0 kW
Max. Input Voltage	1000 V
MPPT Voltage Range	200 - 800 V
Number of MPP Trackers	2
Dimensions (H x W x D)	645 x 431 x 204 mm
Weight	19.9 kg
Protection Rating	IP 65
Operating Temperature Range	-25°C to +60°C
Max. Apparent AC Power	5.0 kVA
AC Nominal Voltage	3~ 230/400 V
AC Voltage Range	184 - 264.5 V
Frequency	50 / 60 Hz
THD	< 3%
Protection Class	I
Maximum AC Power	5000 VA
AC Nominal Frequency	50/60 Hz
DC Input Voltage Range	200 - 1000 V
Number of DC Connections	2
Max. DC Short-circuit Current	18.0 A
Cooling	Active cooling
