WIRING HARNESS AND TAIL LIGHTS
100
KEY PART NO. PART NAME QTY SERIAL NO.
W
R
2
2
1
2
W
R
2
2
1
4
REMARKS
1 5TNC90C0002 WIRING HARNESS 01 X X
2 TNC90B0003 SIGNAL MODULE 01 X X
3 TNC90D0002 AMBER LIGHT FIXTURE 02 X X
4 TNC90B0004 BULBS FOR RED LIGHTS 02 X X
5 TNC90D0001 RED TAIL LIGHT FIXTURE 02 X X
6 TNP50ZV055 LIGHT BRAKET R.H. 01 X X
7 TNP50ZV054 LIGHT BRACKET L.H. 01 X X
8 5TN1836001 SMV SIGN 01 X X
9 5TNP50ZZ165 SUPPORT (SMV) 01 X X
10 TNV30AZ001 WASHER M6 UNI 6592 ZINCED 04 X X
11 5TNV10AZ002 SCREW TE M6x16 UNI 5739 ZINCED 02 X X
12 5TNV20CZ006 NUT-HEX NYL M6-1.00 02 X X
13 5TNV70AZ009 U BOLT M12x160x120 ZINCED 03 X X
14 TNV20CZ003 HEXAGONAL NUT 6S M12 UNI 5588 ZN 04 X X
15 TNV10AZ126 HEX. BOLT H.D. M8x16 UNI5737 04 X X
16 TNL05Z0100 WIRE CLIP 15 X X
17 5TNL05Z0009 TIE BAND 15 X X
