Frontier WR2214 - Page 87

WIDTH ADJUSTMENT ARM MECHANISM
86
KEY PART NO. PART NAME QTY SERIAL NO.
W
R
2
2
1
2
W
R
2
2
1
4
REMARKS
1 5TNP50RV021 SLIDING 01 X X
2 5TNP50ZV134 PLATE FOR SLIDING 01 X X
3 5TNP50QV040 BLADE PANTO 04 X X
4 5TNP50CV031 OPENING ARM 02 X X
5 5TNP50DV086 HINGE FOR PANTO ARM 04 X X
6 5TNP50BV111 ARM FRAME ATTACHMENT L.H. 01 X X
5TNP50BV112 ARM FRAME ATTACHMENT R.H. 01 X X
7 5TNC70BZ025 HINGE L=174 ZN 04 X X
8 5TNC70BZ051 PIVOT TRAF.28 M24 L=95 12 X X
9 TNV20BZ021 SELF LOCKING NUT NY.M24x2 UNI7474 16 X X
10 5TNP70DZ015 SPACER D.29 L=15 ZN 08 X X
11 TNV10AZ016 SCREW TE M10x30 UNI 5739 ZINCED 10 X X
12 TNV20CZ003 NUT METABLOCK M12 DIN 980 ZINCED 20 X X
13 5TNV10AZ136 SCREW TE M12x 40 10.9 UNI5739 20 X X
14 5TNV85A0009 NYLON 119x55x10 04 X X
15 5TNV85A0011 NYLON 140x55x10 04 X X
16 TNV99AZ001 GREASER 10 MB UNI 7663-A 04 X X
