KEY PART NO. PART NAME QTY SERIAL NO.
W
R
2
2
1
2
W
R
2
2
1
4
REMARKS
1 5TNC22A0051 HOSE SAE100 R1 L=8000 9/16-18 JIC 02 X X
2 5TNC50BN230 CYLINDER 2 1/2"x36" 01 X X
3 5TNV85B0006 CABLE CHAIN 01 X X
4 5TNC25H0007 RESTRICTOR 9/16"-18 JIC 3,5 02 X X
5 TNC25F0010 WASHER + OR 1/2" 02 X X
6 TNC25E0001 FAST FLUID CONNECTOR 1/2" 02 X X
7 5TNV10AZ002 SCREW TE M6x16 UNI 5739 ZINCED 04 X X
8 TNC25A0004 90° ELBOW ADAPTER 3/8 NPTF-9/16-18 02 X X
9 5TNC70DZ006 COVER 6 HOSES GUIDE 04 X X
10 TNV20CZ002 NUT METABLOCK M10 DIN 980 ZINCED 04 X X
11 TNV40CZ002 SPLIT PIN D=5x40 UNI 1336 ZINCED 04 X X
12 TNV30AZ001 WASHER M6 UNI 6592 ZINCED 08 X X
13 TNV20AZ001 HEXAGONAL NUT 6S M6 UNI5588 ZINCED 08 X X
14 TNC70BZ012 PIVOT FOR CYLINDER ZINCED 02 X X
SEALS SPARE PARTS CODES:
TO ORDER THE SEALS KIT REFER TO THE PRINTED SEALS CODE ON HYDRAULIC JACK STEEL CYLINDER.
IF NOT AVAILABLE (NOT PRINTED), ORDER 5TNC50A0116
HYDRAULIC PLANT (OPENING-CLOSING)
