Frontier WR2214 - Page 97

96
FLEX FRAME FOR 14 WHEELS ONLY
KEY PART NO. PART NAME QTY SERIAL NO.
W
R
2
2
1
2
W
R
2
2
1
4
REMARKS
1 5TNP50AV415 EXTENSION FLEX RH FOR 2 FINGER WHEEL 1 X
2 5TNP50AV413 EXTENSION FLEX LH FOR 2 FINGER WHEEL 1 X
3 5TNP50HV060 PIVOTING BRACKET FOR FRAME 2 X
4 5TNP50MV012 BLADE L=700 2 X
5 5TNP50MV033 BLADE L=980 2 X
6 5TNP70EZ442 LIFT TUBE L=1740 2 X
7 5TNC70BZ063 PIVOT 2 X
8 5TNV20BZ015 SELF LOCKING NUT NYLON M30 UNI7473 2 X
9 5TNS90CZ035 LIFT TUBE JOINT 2 X
10 5TNP50ZZ139 BUSH WITH DRILLED PLATE 2 X
11 TNV10AZ011 SCREW TE M8x50 UNI 5737 ZINCED 10 X
12 TNV20BZ001 SELF LOCKING NUT M8 UNI 7474 ZINC 14 X
13 5TNV10AZ132 SCREW TE M14x 40 10.9 UNI5737 12 X
14 TNV20CZ004 NUT METABLOCK M14 DIN 980 ZINCED 28 X
15 5TNV10AZ100 SCREW TE M12x30 UNI 5739 ZINCED 8 X
16 TNV20CZ003 NUT METABLOCK M12 DIN 980 ZINCED 12 X
17 TNV99AZ001 GREASER 10 MB UNI 7663-A 4 X
18 5TNP50DV092 WHEEL SUPPORT ANGLED RH 1 X
5TNP50DV093 WHEEL SUPPORT ANGLED LH 1 X
19 5TNV10AZ148 SCREW M 12x140 10.9 UNI5737 2 X
20 5TNP50MZ055 PLATE 2 X
21 5TNP50ZV320 REINFORCEMENT 2 X
22 5TNP70PZ147 PLATE 6 X
23 TNV10AZ135 SCREW M 14x160 10.9 UNI5737 12 X
