Frontier WR2214 - Page 99

KEY PART NO. PART NAME QTY SERIAL NO.
W
R
2
2
1
2
W
R
2
2
1
4
REMARKS
1 5TNP50DV114 SUPPORT KICKER WHEELS D2 CE 01 X X
2 5TNP50DV117 SUPPORT LH 01 X X
3 5TNP50DV118 SUPPORT RH 01 X X
4 5TNP50UV021 CONNECTION BAR L=905 01 X X
5 5TNP50UV022 CONNECTION BAR L=445 01 X X
6 5TNP50BV035 ARM CARRYING RAKE WHEEL CENTER 02 X X
7 5TNP70GZ017 RING d=88,9 02 X X
8 5TNP50DV115 GUIDE D2 01 X X
9 TNC45AZ001 CHAIN 02 X X
10 5TNC50BN066 CYLINDER 01 X X
11 5TNC25A0016 FITTING 90° 3/8 NPTF-3/8 NPTF 01 X X
12 5TNC25M0003 VALVE F/F 3/8"NPTF-3/8"NPTF 210 atm. 01 X X
13 TNC25A0003 FITTING F3 3/8 NPTF-9/16-18 JIC 01 X X
14 5TNP20BV006 RAKE WHL LH - CENTRE - 6.4mm GREEN 01 X X
15 5TNC40AZ019 SPRING FOR RAKE ARMS 02 X X
16 TNV50AZ002 U SHACKLE D=8 ROBUR ZINCED 04 X X
17 TNV10AZ075 SCREW TE M20x90 04 X X
18 TNV20BZ019 SELF LOCKING NUT M20 UNI7474 ZN 04 X X
19 TNC25A0004 FITTING 90° 3/8 NPTF-9/16-18 JIC 01 X X
20 TNV99AZ001 GREASER 10 MB UNI 7663-A 02 X X
21 TNV85A0001 BUSHING NYLON 04 X X
22 TNV30BZ007 STEEL B. WASHER 32.2x53x5 ZN 02 X X
23 TNV40CZ002 SPLIT PIN D=5x40 UNI 1336 ZINCED 02 X X
24 TNV10AZ097 SCREW TE M 10x100 02 X X
25 TNV20CZ002 NUT METABLOCK M10 DIN 980 ZINCED 02 X X
26 5TNV70AZ007 U BOLT M12x102x125 ZINCED 04 X X
27 TNV10AZ015 HEX.CAP SCREW TE M10x25 UNI5739 Z 12 X X
28 TNV30AZ004 WASHER M10 UNI6592 ZN 12 X X
29 TNV20AZ003 HEXAGONAL NUT 6S M10 UNI 5588 ZINC 14 X X
30 TNV20CZ003 NUT KLOCK M12 DIN 980 ZINCED 08 X X
31 5TNC70BZ085 PIN (CYLINDER) 02 X X
32 TNV40DZ001 CIRCLIP 04 X X
33 5TNC22A0037 HOSE SAE100 A.P.25 D10 L=900 02 X X
34 5TNP20BV005 RAKE WHL RH - CENTRE - 6.4mm GREEN 04 X X
SEALS SPARE PARTS CODES:
TO ORDER THE SEALS KIT REFER TO THE PRINTED SEALS CODE ON HYDRAULIC JACK STEEL CYLINDER.
IF NOT AVAILABLE (NOT PRINTED), ORDER 5TNC50A0101
CENTER KICKER WHEELS
98
