CHAPTER 3: INSTALLATION INSTRUCTIONS
3-4
If it is necessary to install legs, use the instructions provided in the accessories package shipped with
the fryer.
Note:
In most
cases, the
contactor box
in a Sub Fryer
will have to be
removed to
secure
baseplate to
existing
foundation.
Note:
If nut cannot be secured to bolt
from deck, the hole will have to be
drilled and tapped.
25.00
22.00 1.37
1.50
12.00
25.06
25.06
15.00
Navy Sub Fryer
FRONT
MOUNTING HOLES
Ø.375
4 PLACES
