CHAPTER 3: INSTALLATION INSTRUCTIONS
3-3
TYPICAL
7.098
TYPICAL
2.470
BACK OF FRYER UNIT
26.316
17.515
31.45
33.39
31.62
31.62
FRONT HANDLE
FPH217
MOUNTING HOLES
Ø .625
4 PLACES
17.534 6.913
28.29
2.465
10.580
20.48
20.48
33.38
15.67
FRONT HANDLE
H14/17 Single for Surface Ship
BACK
OF
FRYER UNIT
