CHAPTER 16: PARTS LISTS - H14, H17, H22, FPH17, H14
Sub
16-12
Filter Magic II Filter Pan
Figure 16-7
Item # Part Number Description
1 810-1406 Hold-down Ring
2 900-8827 Filter Screen
3 810-0181 Handle
4 809-0024 Screw, Handle
5 823-2751 Pan, Weld Assembly
6 810-0006 Caster, Swivel
7 810-0005 Caster, Non-swivel
* 809-0256 Nut (Caster mounting)
6 7
5
1
2
3
4
