Frymaster FPH17 Series - Page 58

CHAPTER 16: PARTS LISTS - H14, H17, H22, FPH17, H14
Sub
16-13
* Not shown
Figure 16-8
Item # Part # Description
1 826-1263 Motor (with gasket 816-0093)
2 816-0093 Gasket, Pump/Motor
3 826-1264 Pump (with gasket 816-0093)
4 809-0194 Washer
5 809-0514 Cap Screw, 5/16 – 18
6 823-1356 Disconnect, Filter magic
7 816-0012 O-ring
1
2
3
4
5
7
6
4 2
T1
3 1
T2
8
9
10
11
12
13
