CHAPTER 16: PARTS LISTS - H14, H17, H22, FPH17, H14
Sub
16-14
Item # Part # Description
8 807-0156 Connector, 9-Pin
9 810-1164 Terminal Block
10 807-2434 Relay, 18 Amp, 24V Coil
11 807-0800 Transformer, 120-24 AC
12 900-5250 Box, Filter Control
13 810-1569 Drain Valve, Non-Filtration System
Drain Valve Assembly for Built-In Filtration Systems
Figure 16-9
Item # Part # Description
1 810-1020 Drain Valve, 1-1/4” x 1”
2 823-8137 Bracket, Drain Switch
1
2
COMPRESSION WASHERS
9
PLASTIC WASHER
3
6
4
8
6
7
5
Side View
